| Potentiometre model: | RJ12 series |
| name： |
RJ12 Joystick Potentiometer |
| Main specifications: |
Dimensions: 12mmX12mm |
| Features： |
Small size with reliable performance; Applicable to SMT reflow soldering. |
| Application field： |
Handhold gimbals, gaming controllers and other related electronic devices. It is mainly used for direction control and mode switching. |
ONE、MECHANICAL CHARACTERISTIC
1. Operating Travel: 2.4mm
2. Operating Torque: 110±50 gf
3. Stopp Strength: ≥1Kgf.cm
TWO、ELECTRICAL CHARACTERISTIC
1. Total resistance: 10K±20%
2. Rated power: 0.0125W
3. Rated voltage: AC 50V / DC 5V；
4. Voltage divider error: 44%-56%
THREE、ENDURANCE CHARACTERISTIC
1. Operating life: 100,000 cycles Min
Note: In this catalog, if some parameters or drawings are different from the "Approvalsheet", it's subject to the "Approval sheet".
